Arrow Trailer (VD2-PL)

This fully customizable double-axle action car includes all specified options. Its trailer features two torsional spring axles and supports a maximum loaded weight of 1500 kg / 3306 lbs. Equipped with four extendable manual support legs, it ensures stability on various surfaces. The hydraulically foldable action frame is fitted with class 3 retroreflective foil, enhancing visibility and safety during operation.

Download brochure Find a Dealer

UNIQUE SELLING POINTS

Dual torsional sprung axles, 1350 kg each, with braked lights and parking brake.
Maximum load capacity of 1500 kg with registration.
Fully closed construction with an open bottom for versatility.
Hydraulically foldable action frame with Class 3 retroreflective foil.

Advanced 24V LED arrow configuration compliant with EN12353 guidelines.
Robust solar energy system with 800 Ah maintenance-free batteries.
Galvanized chassis and powder-coated body for durability and corrosion resistance.
Integrated hydraulic jockey wheel and comprehensive charging options.

TECHNICAL SPECIFICATIONS

Trailer fitted with 2 torsional sprung axles, each 1350 kg / 2976 lbs, legally prescribed driving lights, braked, and equipped with a parking brake.
Maximum loaded weight of 1500 kg / 3306 lbs with registration certificate.
Construction (tray) completely closed, with an open bottom for versatility.
Front box equipped with 1 control hatch, fitted with hinges and locks (double-bit locks).
Equipped with 4 extendable hydraulic support legs for stability.
Hydraulically foldable action frame with Class 3 retroreflective foil.
Arrow configuration includes 24V LED lamps, rotatable or fixed setup compliant with EN12353 guidelines, featuring automatic light dimmer.
Arrow and sign D2 (1000mm diameter) hydraulically rotatable.
Action frame designed to ensure retroreflective foil is not visible in transport position.
Includes a 280 Wp solar energy system with a 20A IP65 solar charger, display, and accessories.
Powered by 8 maintenance-free solar glass-mat batteries, 100 Ah 12 Volt each, totaling 800 Ah.
Andreas strips (rumble strips) storage available on the side of the trailer (excluding rumble strips).
Fully galvanized chassis for durability.
Body parts powder coated in your desired color or RAL 1016 in accordance with Dutch RWS requirements.
Features a 175Amp Anderson charging plug fitted at the front.
Equipped with a hydraulic jockey wheel.
Includes a 230Vac battery charger with grid connection, installation, and a 15m charging cable.

ABOUT THE VD2-PL

This fully hydraulic double-axle action trailer is customizable with the options you specify.

ALSO AVAILABLE AS

A chevron design.

OPTIONAL

Andreas strip set.
Wireless remote-control unit.
Optionally equipped with spare wheel.

MOBITRACK

Mobitrack can be integrated into your products, providing accurate and real-time location data. It keeps a detailed record of past locations, allowing you to see where your products have been. Mobitrack is simple to integrate into both new and existing products.

Statistics show that many accidents still occur involving road users and workers. To enhance the safety of both drivers and workers, Mobitrack can be configured to work with safety alert systems. This integration allows it to send alerts to drivers, warning them of nearby workers and significantly increasing safety.

Mobitrack is automatically integrated with a wide range of safety alert systems, including Google, Waze, Flitsmeister, Monotch, and your country’s traffic control system. We are the only manufacturer with such extensive integration across various safety alert platforms.

Additionally, the advanced implementation of the Mobitrack module allows you to request detailed information about your products, ensuring you have all the necessary data at your disposal.

MOBITRACK – SIMPLE

Track your products’ locations accurately in real-time.
Keeps a location history of where your products have been.
Easily integrates with any product.
Display your product in the Mobilityplanner platform for easy access.
Integration with safety alert systems to improve safety and send warnings.
~~Request additional information from your products: arrow left/right, cushion down/up, lights on/off etc.~~

Learn more

MOBITRACK – ADVANCED

Track your products’ locations accurately in real-time.
Keeps a location history of where your products have been.
Easily integrates with any product.
Display your product in the Mobilityplanner platform for easy access.
Integration with safety alert systems to improve safety and send warnings.
Request additional information from your products: arrow left/right, cushion down/up, lights on/off etc.
